Shacman F3000 Dump Truck
1.Powerful diesel engine
2.Large payload capacity
3.Hydraulic tipping system
4.Reliable and durable construction
5.Easy to operate and maintain
- Shacman
- China
- 15-20 days
- 10000 Unit/Month
- Information
Descriptions
Shacman dump truck is a workhorse designed to tackle even the most demanding jobs. Built for durability and power, this 10-wheeler is a popular choice for construction sites, quarries, and any operation requiring heavy-duty hauling.F3000 boasts a robust chassis and a 6x4 drivetrain configuration, providing exceptional stability and load handling. This translates to confident maneuvering on uneven terrain and a surefooted ride when carrying heavy cargo.
Choose from a range of engine options, all offering impressive horsepower (from 351 to 450hp) to conquer even the steepest inclines and haul the heaviest loads with ease. Available in both 6x4 and 8x4 configurations, the F3000 provides superior traction and stability for any terrain.
Drive configurations: Choose from 6x4 and 8x4 drive configurations
Engineered for Power：F3000 X3000 M3000 H3000 L3000
Orange
White
Green
Red
6X4 10 Wheels Dump Truck
8X4 12 Wheels Dump Truck
Details
Parameters
| Drive | 6x4 | 8x4 | ||
| GCW (t) | 50 | 70 | 90 | |
| Cab | Type | Medium-length flat roof | Standard | |
| Suspension | Hydraulic suspension | |||
| Seat | Hydraulic main seat | |||
| Air conditioner | Electric automatic constant temperature AC | |||
| Engine | Model | WP10/WP12/M10/ISM11 | ||
| Emission standard | EURO II - EURO V | |||
| Rated power (hp) | 336/340/375/380/385/400/420/430 | 380/385/400/420/430/460 | ||
| Transmission | Model | FAST MT (10/12) | ||
| Main configuration | Front axle | 9.5t | ||
| Axle | Rear axle | 16t | ||
| Ratio | 5.262/5.92 | 4.769/5.262 | 5.262/4.769 | |
| Dimension (mm) | 850X300(8+7) | 850X320(8+7+8) | ||
| Wheel base (mm) | 3775+1400 | 1800+3575+1400/1800+3775+1400 | ||
| Chassis | Wheel overhang (mm) | 850 | 1000 | |
| Fuel tank | 400L aluminum alloy | |||
| Tire | 12.00R20 | |||
| Suspension | Front and rear multi-leaf springs | |||
| Tipper container | 5600x2300x1500 | 7400x2300x1500 | ||
| Applicable road condition | Muddy and potholed roads with steep grades | |||
| Applicable condition | Economic/Max speed (km/h) | 40-55/75 | 45-60/85 | 40-60/80 |
| Basic equipment | Electric window lifter, metal bumper, two-stage pedal, water tank protection grille | |||
